GS TOOLING-337-638; 5.0mm ER11 SPRING COLLET, SEALED

data-zoom=

GS-337-638

Brand: GS TOOLING

Obsolete

MSRP $57.46

Price: $46.00

$46.00

39871626707117


GS TOOLING Part Number: GS-337-638
GS TOOLING ER11 SPRING COLLET is made of special elastic steel material under excellent heat treatment and precise grinding process, so it has precise accuracy, powerful clamping ability, and is durable. It can be widely used for boring, milling, drilling and tapping as well as for grinding operations.

  • Sealed For Coolant Through Applications
  • Pressure Resistance Tested To 2000 PSI
  • Approximately 1/32" Collapse With Full Accuracy
  • High Precision With Runout Of Only 10 Microns (0.01mm or 0.0004")

***Product image may be different than actual product.


Brand: GS TOOLING
Type: ER Collets
Collet Series: ER11
Collet Size: 5.0mm
Collet Capacity Range: .177"-.196"
TIR: 0.01mm/0.0004"
Collet Length: 18mm
Collet Outside Diameter: 11.5mm
Prop 65: Yes
Country Of Origin: Import
Obsolete
